Rotary screw compressors are heavily relied on in natural gas operations, from extraction to processing. Their design and performance make them indispensable for maintaining flow and pressure across the supply chain. This article examines the role of rotary screw compressors in natural gas operations, highlighting their importance in efficient compression.
1. Gas Gathering
In gas gathering systems, rotary screw compressors are used to boost the pressure of raw natural gas as it exits the wellhead. This step ensures the gas can be transported efficiently to processing facilities through pipelines.
At this stage, compressors must handle variable gas compositions, often with high levels of moisture or impurities. Rotary screw designs excel in these environments due to their ability to operate under fluctuating loads without compromising performance.
Additionally, their compact configuration makes them suitable for installation in remote or space-constrained gathering sites.
2. Gas Processing
Rotary screw compressors help maintain operational pressure in natural gas processing plants. During separation, dehydration, and gas sweetening, these compressors regulate the flow of gas through various stages of treatment. Their inherent precision allows for consistent performance, which is critical to maximizing throughput and maintaining the efficiency of downstream processes.
Materials used in their construction can be selected to resist the corrosive effects of sour gas or other byproducts encountered in processing, ensuring long service life in demanding conditions.
3. Pipeline Compression
For natural gas transportation, rotary screw compressors are deployed at pipeline stations to sustain the pressure necessary for moving gas over long distances. They deliver uniform flow rates under varying conditions which is essential for minimizing energy loss during transport.
The modular design of these compressors also allows them to be scaled or adjusted based on the pipeline’s requirements, while advanced cooling systems prevent overheating during continuous operation.
Pipeline compression stations often operate in remote areas, and the rugged build of rotary screw compressors ensures they can withstand harsh environmental factors while requiring minimal intervention.
4. Underground Storage
Rotary screw compressors play a dual role in underground natural gas storage, managing both injection and withdrawal cycles. During injection, the compressors elevate gas pressure for storage in depleted reservoirs or salt caverns. During peak demand, they reverse the process, extracting gas and delivering it back into the pipeline network at usable pressures.
These compressors are designed to operate across a wide range of pressures and temperatures, adapting to changes in storage conditions. Their ability to maintain consistent output during fluctuating operations makes them invaluable for balancing supply and demand.
5. Enhanced Oil Recovery (EOR)
In enhanced oil recovery operations, rotary screw compressors are used for gas lift techniques, where natural gas is injected into reservoirs to improve oil flow. Compressor controls ensure optimal injection rates which are vital for maximizing recovery without overpressurizing the reservoir.
Given the high-pressure environment of EOR applications, rotary screw compressors are engineered for durability and consistent performance, even in extreme conditions.
Find Your Compression Solution Today
Rotary screw compressors are essential to the natural gas industry, enabling efficient gas movement and processing across every stage of the value chain. If you’re in need of new equipment, Contact 24-7 Compression to discuss solutions for your natural gas operations.
Rotary screw compressors play an essential role in natural gas operations, providing reliable and efficient gas compression that keeps everything running smoothly. In this blog, we’ll explore the top five benefits that make these compressors a go-to choice for natural gas applications.
1. Continuous and Reliable Operation
Rotary screw compressors are built for continuous use, making them perfect for natural gas operations that run around the clock. Unlike compressors that require frequent shutdowns for maintenance, these machines can handle non-stop workloads with minimal interruptions, keeping your operations on track.
2. High Efficiency
When it comes to compressing large volumes of natural gas, efficiency is critical. Rotary screw compressors are designed to maximize output while minimizing energy consumption. This efficiency is particularly valuable in the natural gas industry, where optimizing performance while controlling costs is essential for long-term profitability.
3. Durability for Demanding Conditions
Natural gas environments can be tough, with high pressures and challenging conditions. Rotary screw compressors are designed to withstand these demands, offering long-lasting performance. Their durable construction ensures they can handle the rigors of gas compression, leading to fewer breakdowns and extended service life.
4. Minimal Vibration and Noise
Rotary screw compressors run smoother and quieter than other types of compressors, such as reciprocating models. This is due to the balanced rotation of the screws, which reduces vibration and noise levels. In natural gas applications, this smoother operation not only minimizes wear and tear on equipment but also contributes to a safer and more comfortable working environment.
5. Low Maintenance Requirements
One of the biggest advantages of rotary screw compressors is their low maintenance needs. The design reduces the number of components that need regular servicing, which means less downtime and lower maintenance costs overall. For natural gas operators, this translates into better efficiency and fewer unexpected repairs.
Conclusion: A Smart Choice for Natural Gas Operations
For anyone involved in natural gas operations, rotary screw compressors offer the perfect balance of reliability, efficiency, and durability. These compressors are also known for their low maintenance requirements, making them a cost-effective choice for long-term use. Their ability to run continuously, handle large gas volumes, and require minimal maintenance makes them an invaluable asset.
Connect With an Equipment Supplier Today
To learn more about how rotary screw compressors can benefit your operations, contact 24-7 Compression today. Our team is happy to set you up with the compression equipment you need.
Rotary screw compressors are a critical asset in gas operations, where reliability and efficiency can't be overlooked. This FAQ guide delivers in-depth technical insights into rotary screw compressors, equipping industry professionals with the knowledge necessary to optimize performance and make informed decisions.
What Is a Rotary Screw Compressor?
A rotary screw compressor is a type of gas compressor that uses a rotary-type positive displacement mechanism to compress gas. Unlike traditional air compressors, rotary screw compressors are often used in industrial applications, including natural gas compression, vapour recovery, and biogas handling. These compressors work by trapping gas between two helical screws (rotors) and compressing it as the rotors rotate. The compressed gas is then discharged at a higher pressure, making it ideal for industrial processes requiring consistent and reliable compression.
How Does a Rotary Screw Compressor Work?
Rotary screw compressors operate by utilizing two meshing helical screws, also known as rotors, which rotate in opposite directions. As the rotors turn, gas is trapped in the space between them and the casing. The continuous rotation reduces the volume of the trapped gas, increasing its pressure. This highly efficient process allows the compressor to handle large volumes of gas at varying pressures. The lack of valves and other components that wear out quickly ensures that rotary screw compressors can operate continuously with minimal maintenance.
What Are the Key Benefits of Rotary Screw Compression?
Rotary screw compressors offer several key benefits, including:
- High Efficiency: They are designed to operate efficiently even under continuous use, providing consistent compression with low energy consumption.
- Durability: Built to withstand demanding industrial environments, rotary screw compressors have a long operational life.
- Flexibility: Many screw compressor models offer internal capacity control, allowing operation at as low as 10% capacity using a slide valve. This flexibility is valuable for applications with variable demand.
- Smooth Operation: The rotary screw design ensures minimal vibration and noise, leading to smoother operation and reduced wear on components.
- Low Maintenance: Screw compressors require minimal maintenance due to the closed-loop oil circulation system, which typically operates without a separate pump. This reduces the need for frequent servicing.
- No Valves: They often feature fixed suction and discharge ports, eliminating the need for valves, which can wear out or require regular maintenance.
- Balanced Rotation: With no reciprocating motion and only high-speed balanced rotation, screw compressors experience less mechanical stress and have a smoother operation.
- Cost-Effective: Rotary compressors can achieve high rotational speeds, sometimes up to 10,000 rpm with a gearbox, allowing them to displace more gas than slower alternatives with equivalent swept volumes. This efficiency translates to less equipment needed to handle large volumes of gas.
- Efficient Cooling: The mixing of gas and oil within the compressor frame absorbs heat from the gas, enabling more compression ratios in a single stage without the need for an intercooler, additional cylinders, or extensive piping.
What Are the Disadvantages of Rotary Screw Compressors?
As is the case with all equipment, drawbacks inherent to a design must also be assessed. Here's what we think rotary screw compressors fall behind on:
- Limited Discharge Pressures: Screw compressors are generally limited to discharge pressures of around 375 psig (2,585 kPag), depending on the manufacturer, which can restrict their use in applications requiring higher pressures.
- Inefficiency in High Ratio Applications: As compression ratios exceed 5, screw compressors become increasingly less efficient, consuming more power for compression. While the initial capital cost may be lower than a multi-stage reciprocating compressor, the ongoing power costs can be significantly higher.
What Are the Applications of Rotary Compressors in the Natural Gas Industry?
Rotary screw compressors are widely used in the gas industry for applications such as:
- Natural Gas Compression: These compressors are used to compress natural gas for transportation through pipelines.
- Vapour Recovery: Rotary screw compressors are employed in vapour recovery units (VRUs) to capture and compress gas vapours for reuse, reducing emissions and improving efficiency.
- Biogas Processing: In biogas plants, rotary screw compressors are used to compress biogas for storage or further processing.
- Field Gathering: They are essential in gathering systems where gas from multiple wells is collected, compressed, and sent to processing facilities.
What's the Difference Between Oil-Injected and Oil-Free Rotary Screw Compressors?
The primary difference between oil-injected and oil-free rotary screw compressors lies in how they handle lubrication and cooling:
- Oil-Injected Compressors: These compressors use oil to lubricate and cool the rotors, which helps seal and cool the compressed gas. They are typically used in applications where oil contamination is not a concern.
- Oil-Free Compressors: On the other hand, oil-free compressors do not use oil in the compression chamber. They rely on other means for cooling and are ideal for applications where the purity of the compressed gas is critical, such as in food processing or pharmaceutical industries.
What Are Variable Speed Rotary Screw Compressors?
Variable speed rotary screw compressors are designed to adjust their motor speed based on the air or gas demand. Unlike fixed-speed compressors, variable speed compressors can slow down or speed up as needed, resulting in significant energy savings. These compressors are particularly beneficial in applications where the demand for compressed gas fluctuates, as they can provide the necessary compression while minimizing energy consumption.
What Are the Common Maintenance Needs for Rotary Screw Compressors?
Common maintenance practices include:
- Oil Changes: Regular oil changes are necessary for oil-injected compressors to maintain lubrication and cooling efficiency.
- Filter Replacements: Both air and oil filters should be replaced regularly to prevent contamination and ensure optimal performance.
- Belt Inspections: Regularly inspect and adjust belts to maintain proper tension and avoid slippage.
- Leak Checks: Regularly check for any gas leaks, as they can reduce efficiency and cause safety hazards.
- Professional Servicing: Scheduling regular inspections and servicing by qualified technicians to address any potential issues before they lead to significant downtime.
How Long Do Rotary Screw Compressors Typically Last?
With proper maintenance, rotary screw compressors can have a long operational life, often lasting between 10 to 20 years or more. The longevity of the compressor depends on factors such as operating conditions, maintenance practices, and the quality of the compressor components. Investing in regular maintenance and high-quality parts can significantly extend the lifespan of the compressor.
What Are the Advantages of Oil-Free Rotary Screw Compressors?
Oil-free rotary screw compressors offer several advantages, particularly in applications where air or gas purity is critical:
- No Risk of Contamination: Since no oil is used in the compression chamber, there is no risk of oil contaminating the compressed gas.
- Lower Maintenance Costs: Oil-free compressors typically require less maintenance as there is no need for regular oil changes or oil filter replacements.
- Compliance with Industry Standards: Oil-free compressors are often required in industries such as food and beverage, pharmaceuticals, and electronics, where strict purity standards must be met.
What Sets Rotary Screw Compressor Technology Apart from the Rest?
Rotary screw compressor technology improves efficiency through several design features:
- Large Rotors: Larger rotors operate at lower speeds, reducing wear and tear while improving compression efficiency.
- Precision Engineering: The precise meshing of the rotors ensures minimal gas leakage, maximizing compression efficiency.
- Variable Speed Drives: Compressors with variable speed drives adjust their output to match demand, reducing energy consumption during periods of low demand.
Rotary Screw Compressors vs Reciprocating Compressors: What's the Difference?
Rotary screw compressors and reciprocating compressors are both widely used in natural gas applications, but they differ significantly in design and operation. Rotary screw compressors offer continuous operation, lower maintenance requirements, and smoother, quieter operation due to their lack of reciprocating motion. They are ideal for applications requiring a steady flow of compressed gas. In contrast, reciprocating compressors, which use pistons to compress gas, are better suited for high-pressure applications and offer higher efficiency at lower flow rates. However, they generally require more maintenance due to their moving parts and can be noisier during operation.
How Do Rotary Screw Compressors Compare to Centrifugal Compressors?
Rotary screw compressors are typically preferred over centrifugal compressors in applications where a steady, medium-pressure gas flow is required. Unlike centrifugal compressors, which rely on high-speed rotating impellers to compress gas, rotary screw compressors use meshing helical screws to compress gas more gradually.
This makes them more efficient at lower to medium flow rates and pressures. Additionally, rotary screw compressors have fewer moving parts, leading to reduced maintenance costs and improved reliability in demanding industrial environments. While centrifugal compressors excel at very high flow rates and are often used in large-scale applications, they are less effective at handling varying loads compared to the more flexible rotary screw compressors.
Contact Your Canadian Compression Experts for More Information Today
Rotary screw compressors are essential for the gas industry due to their efficiency, reliability, and low maintenance requirements. Whether you want to upgrade your current system or invest in a new one, 24-7 Compression can provide expert guidance and top-quality equipment (including rentals). Contact us today to learn more about our compressor equipment and how we can support your business needs.
